Install Zimbra Multi Server on Ubuntu 20.04 (Part 1)

5 min read

Install Zimbra Multi Server on Ubuntu 20.04 (Part 1)

Hi Dude. in a previous article I’ve posted about installing zimbra single server on Ubuntu 20.04. And then in this article I want to post about install zimbra multi server on ubuntu 20.04.

With several stages that must be done in sequence. In my case, I created a server summary table which we will install later. There are 4 servers in total, see the table below.

NoServerServer IP AddressHostname
1LDAP dan DNS Server10.12.12.10ldap.habibza.in
2Mailbox 1 10.12.12.11mbox1.habibza.in
3Transport/MTA/proxy10.12.12.12mta.habibza.in
4Mailbox 210.12.12.13mbox2.habibza.in
Table Plan Install Zimbra Multi Server.

To make it easier for users to access later, I will create a global domain host access as a proxy later.

Global Access Email Server ==> 10.12.12.12  mail.habibza.in

So the user does not have to know the name of the server hostname one by one. Just know 1 server that will be accessed later.

In my case, i will use three scope server base on service served. That is Zimbra LDAP, Mailbox, and MTA.

Order Installation Zimbra Multi Server on Ubuntu

Before starting the installation process, we will first prepare a roadmap for installation zimbra multi server on ubuntu 20.04.

  1. ZCS LDAP server(s), with additional service:
    • DNS, use Bind
    • NTP, Required system clocks are synced on all servers.
  2. ZCS Mailbox server(s) options:
    • Zimbra Logger
    • ZCS Mailbox server(s)
    • Zimbra Web Application
  3. ZCS MTA server(s), with additional service:
    • Zimbra Memcache.
    • Zimbra Proxy.
    • AS/AV.

Preparation for Zimbra LDAP

Step 1 through step 3 are performed for each server to be installed. Open an SSH session to the Zimbra server and follow the steps below:

Set /etc/hosts and Static IP Address Static for LDAP

In this case, i am use 10.12.12.10 for Zimbra LDAP.

root@ldap:~# vim /etc/netplan/00-installer-config.yaml
# This is the network config written by 'subiquity'
network:
  ethernets:
    ens33:
      dhcp4: no
      addresses:
       <strong> - 10.12.12.10/24</strong>
      gateway4: 10.12.12.2
      nameservers:
          addresses: [10.12.12.10, 8.8.8.8]
  version: 2

Do netplan apply. and then Set /etc/hosts.

root@ldap:~# vim /etc/hosts
127.0.0.1 localhost

10.12.12.10 ldap.habibza.in   ldap
10.12.12.11 mbox1.habibza.in mbox1
10.12.12.12 mta.habibza.in    mta
10.12.12.13 mbox2.habibza.in mbox2

Setting Hostname and Date Time

This is command to set hostname in Ubuntu.

hostnamectl set-hostname ldap.habibza.in

And then set time and date.

timedatectl set-timezone Asia/Jakarta

Disable firewall

Why disable firewall? I am prefer disable firewall because:

  • Servers is under Zone DMZ. Firewall role taken by router, so can reduce resource.
  • Minimizes troubleshooting of open ports and closed ports of communication that occur between servers. And also service security internal permit and not permit like selinux on Centos/Redhat and apparmor on Ubuntu.
systemctl stop apparmor.service
systemctl disable apparmor.service
systemctl stop ufw.service
systemctl disable ufw.service

Install NTP Server.

Set NTP Server on LDAP Server. Why install NTP in LDAP? This is LDAP server is firts time must running on Zimbra Multi Server.

apt install ntp ntpdate

Modify ntp server in /etc/ntp.conf. Just allow local subnet can query time server.

restrict 10.0.0.0 mask 255.0.0.0 nomodify notrap

And then restart service NTP.

systemctl restart ntp

Install DNS Bind

Install DNS Bind for local authoritative.

apt install bind9

Modify named.conf. options

root@ldap:/# vim /etc/bind/named.conf.options

        recursion yes;
        allow-query { 127.0.0.1; 10.0.0.0/8; };
        allow-transfer { none; };
        forwarders { 8.8.8.8; 1.1.1.1; };
        listen-on port 53 { 127.0.0.1; 10.12.12.10; };
        version "not current available";
        querylog yes;

Touch file /etc/bind/named.conf.local.

root@ldap:/# vim /etc/bind/named.conf.local

zone "habibza.in" {
        type master;
        file "/etc/bind/db.habibza.in";
};

Create file /etc/bind/db.habibza.in

root@ldap:/# vim /etc/bind/db.habibza.in


$TTL    604800
@       IN      SOA     ns1.habibza.in. root.habibza.in. (
                              2         ; Serial
                         604800         ; Refresh
                          86400         ; Retry
                        2419200         ; Expire
                         604800 )       ; Negative Cache TTL
;
@               IN      NS      ns1.habibza.in.
@               IN      A       10.12.12.12
@               IN      MX      0      mail.habibza.in.
ldap            IN      A       10.12.12.10
ns1             IN      A       10.12.12.10
mbox1           IN      A       10.12.12.11
mta             IN      A       10.12.12.12
mbox2           IN      A       10.12.12.13
mail            IN      A       10.12.12.12

After finish, restart service bind.

root@ldap:/# systemctl restart bind9.service
root@ldap:/# systemctl status bind9.service
 named.service - BIND Domain Name Server
     Loaded: loaded (/lib/systemd/system/named.service; enabled; vendor preset: enabled)
     Active: active (running) since Thu 2022-07-28 11:05:28 WIB; 7s ago
       Docs: man:named(8)
   Main PID: 125121 (named)
      Tasks: 8 (limit: 1037)
     Memory: 17.0M
     CGroup: /system.slice/named.service
             └─125121 /usr/sbin/named -f -u bind

Jul 28 11:05:28 ldap.habibza.in named[125121]: configuring command channel from '/etc/bind/rndc.key'
Jul 28 11:05:28 ldap.habibza.in named[125121]: command channel listening on ::1#953
Jul 28 11:05:28 ldap.habibza.in named[125121]: managed-keys-zone: loaded serial 3
Jul 28 11:05:28 ldap.habibza.in named[125121]: zone 0.in-addr.arpa/IN: loaded serial 1
Jul 28 11:05:28 ldap.habibza.in named[125121]: zone 127.in-addr.arpa/IN: loaded serial 1
Jul 28 11:05:28 ldap.habibza.in named[125121]: zone 255.in-addr.arpa/IN: loaded serial 1
Jul 28 11:05:28 ldap.habibza.in named[125121]: zone localhost/IN: loaded serial 2
Jul 28 11:05:28 ldap.habibza.in named[125121]: zone habibza.in/IN: loaded serial 2
Jul 28 11:05:28 ldap.habibza.in named[125121]: all zones loaded
Jul 28 11:05:28 ldap.habibza.in named[125121]: running

In this LDAP Server, stop and disable service systemd-resolved.service. Because role resolver take over by bind9.service. After that re-create /etc/resolv.conf

systemctl stop systemd-resolved.service
systemctl disable systemd-resolved.service
rm -rf /etc/resolv.conf
vim /etc/resolv.conf

nameserver 127.0.0.1
domain habibza.in

Test lookup, and make sure name server running properly with answer form 127.0.0.1

root@ldap:/# nslookup ldap.habibza.in
Server:         127.0.0.1
Address:        127.0.0.1#53

Name:   ldap.habibza.in
Address: 10.12.12.10

root@ldap:/# nslookup mail.habibza.in
Server:         127.0.0.1
Address:        127.0.0.1#53

Name:   mail.habibza.in
Address: 10.12.12.12

root@ldap:/# nslookup mbox1.habibza.in
Server:         127.0.0.1
Address:        127.0.0.1#53

Name:   mbox1.habibza.in
Address: 10.12.12.11

root@ldap:/# nslookup mta.habibza.in
Server:         127.0.0.1
Address:        127.0.0.1#53

Name:   mta.habibza.in
Address: 10.12.12.12

Install Zimbra LDAP

At first, download tarball from official repository.

See also  Zimbra Collaboration Postscreen Implementation

REMEMBER. In this server just install zimbra-ldap service.

wget https://files.zimbra.com/downloads/8.8.15_GA/zcs-8.8.15_GA_4179.UBUNTU20_64.20211118033954.tgz
tar -zxvf zcs-8.8.15_GA_4179.UBUNTU20_64.20211118033954.tgz
cd zcs-8.8.15_GA_4179.UBUNTU20_64.20211118033954
./install.sh

Operations logged to /tmp/install.log.v39fi0HW
Checking for existing installation...
    zimbra-drive...NOT FOUND
    zimbra-imapd...NOT FOUND
    zimbra-patch...NOT FOUND
    zimbra-mta-patch...NOT FOUND
    zimbra-proxy-patch...NOT FOUND
    zimbra-license-tools...NOT FOUND
    zimbra-license-extension...NOT FOUND
    zimbra-network-store...NOT FOUND
    zimbra-network-modules-ng...NOT FOUND
    zimbra-chat...NOT FOUND
    zimbra-talk...NOT FOUND
    zimbra-ldap...NOT FOUND
    zimbra-logger...NOT FOUND
    zimbra-mta...NOT FOUND
    zimbra-dnscache...NOT FOUND
    zimbra-snmp...NOT FOUND
    zimbra-store...NOT FOUND
    zimbra-apache...NOT FOUND
    zimbra-spell...NOT FOUND
    zimbra-convertd...NOT FOUND
    zimbra-memcached...NOT FOUND
    zimbra-proxy...NOT FOUND
    zimbra-archiving...NOT FOUND
    zimbra-core...NOT FOUND


----------------------------------------------------------------------
PLEASE READ THIS AGREEMENT CAREFULLY BEFORE USING THE SOFTWARE.
SYNACOR, INC. ("SYNACOR") WILL ONLY LICENSE THIS SOFTWARE TO YOU IF YOU
FIRST ACCEPT THE TERMS OF THIS AGREEMENT. BY DOWNLOADING OR INSTALLING
THE SOFTWARE, OR USING THE PRODUCT, YOU ARE CONSENTING TO BE BOUND BY
THIS AGREEMENT. IF YOU DO NOT AGREE TO ALL OF THE TERMS OF THIS
AGREEMENT, THEN DO NOT DOWNLOAD, INSTALL OR USE THE PRODUCT.

License Terms for this Zimbra Collaboration Suite Software:
https://www.zimbra.com/license/zimbra-public-eula-2-6.html
----------------------------------------------------------------------
Do you agree with the terms of the software license agreement? [N] y
Use Zimbra's package repository [Y]

Warning: apt-key output should not be parsed (stdout is not a terminal)
Importing Zimbra GPG key
Configuring package repository
Checking for installable packages

Found zimbra-core (local)
Found zimbra-ldap (local)
Found zimbra-logger (local)
Found zimbra-mta (local)
Found zimbra-dnscache (local)
Found zimbra-snmp (local)
Found zimbra-store (local)
Found zimbra-apache (local)
Found zimbra-spell (local)
Found zimbra-memcached (repo)
Found zimbra-proxy (local)
Found zimbra-drive (repo)
Found zimbra-imapd (local)
Found zimbra-patch (repo)
Found zimbra-mta-patch (repo)
Found zimbra-proxy-patch (repo)

Select the packages to install
Install zimbra-ldap [Y]
Install zimbra-logger [Y] n
Install zimbra-mta [Y] n
Install zimbra-dnscache [N] n
Install zimbra-snmp [Y] n
Install zimbra-store [Y] n
Install zimbra-apache [Y] n
Install zimbra-spell [Y] n
Install zimbra-memcached [Y] n
Install zimbra-proxy [Y] n
Checking required space for zimbra-core

Installing:
    zimbra-core
    zimbra-ldap

The system will be modified.  Continue? [N]
Exit? [N] n
The system will be modified.  Continue? [N] y
Beginning Installation - see /tmp/install.log.v39fi0HW for details...
...
...

Running Post Installation Configuration:
Operations logged to /tmp/zmsetup.20220410-123639.log
Installing LDAP configuration database...done.
Setting defaults...

DNS ERROR resolving MX for ldap.habibza.in
It is suggested that the domain name have an MX record configured in DNS
Change domain name? [Yes]
Create domain: [ldap.habibza.in] habibza.in
done.
Checking for port conflicts

Main menu

   1) Common Configuration:
   2) zimbra-ldap:                             Enabled
   s) Save config to file
   x) Expand menu
   q) Quit

*** CONFIGURATION COMPLETE - press 'a' to apply
Select from menu, or press 'a' to apply config (? - help) 1


Common configuration

   1) Hostname:                                ldap.habibza.in
   2) Ldap master host:                        ldap.habibza.in
   3) Ldap port:                               389
   4) Ldap Admin password:                     set
   5) Store ephemeral attributes outside Ldap: no
   6) Secure interprocess communications:      yes
   7) TimeZone:                                Asia/Bangkok
   8) IP Mode:                                 ipv4
   9) Default SSL digest:                      sha256

Select, or 'r' for previous menu [r] r

Main menu

   1) Common Configuration:
   2) zimbra-ldap:                             Enabled
   s) Save config to file
   x) Expand menu
   q) Quit

*** CONFIGURATION COMPLETE - press 'a' to apply
Select from menu, or press 'a' to apply config (? - help) a
Save configuration data to a file? [Yes]
Save config in file: [/opt/zimbra/config.12512]
...
...

Configuration complete - press return to exit

After install zimbra ldap finished. Check Status

zimbra@ldap:~$ zmcontrol status
Host ldap.habibza.in
        ldap                    Running
        stats                   Running
        zmconfigd               Running

Next, continue to install zimbra mailbox and Zimbra MTA in part 2 article.

See also  Easy Install Postfix Ubuntu 20.04

Let's Buy Me Coffee.

Buy Me a Coffee at ko-fi.com

https://saweria.co/habibzain
https://ko-fi.com/habibzain

habibzain Just husband, father and enthusiastic men about System Administration. Love to write short article about it. Perhaps can help and be useful for others.

Easy Create Laravel Project with Composer

Requirement Laravel, a popular PHP framework, is renowned for its elegant syntax and robust features, making it a top choice for web developers. One...
habibzain
1 min read

Virtualbox Change Storage Size

Changing the storage size of a virtual machine in VirtualBox involves a few steps. Here’s a general guide. Backup your Virtual Machine (VM) Before...
habibzain
35 sec read

Easy Setup Logrotate Nginx Ubuntu

Log rotation is an important aspect of managing log files on a Linux system, including those generated by Nginx. Logrotate is a utility that...
habibzain
1 min read

Leave a Reply

Your email address will not be published. Required fields are marked *

Never miss good article from us, get weekly updates in your inbox
